Miniature - Cobot S0

High-precision collaborative miniature robot arm with 6 axes - S0 series.

In the dynamic world of automation, flexibility and efficiency are paramount. Have you had enough of inflexible production lines? With the mini robots from CPC, we offer 2 series of small robot arms: DB0 and S0.

These compact robots are characterized by a small footprint, low weight, low noise and maximum precision. The S0 series is collaborative and features a foldable design for greater flexibility, while the DB0 offers high rigidity and precise movements. Both series redefine automation and offer unparalleled versatility for energy-efficient, mobile and emerging market applications.

The S0 is the smallest collaborative robot arm on the market, with an arm weight of just 4 kg and a maximum payload of 1 kg.

The small size and light weight allow the S0 to move flexibly even in confined spaces and to choose the best mode and position at all times to meet the requirements of the production line. The unique folding design creates multiple path planning options for more movement efficiency.

These features characterize the S0:

- Small footprint
- Low weight
- Best-in-class repeatability
- Collaborative
- Foldable design
- Low noise
- Best-in-class torque motor
- Powerful servo drive
- High-resolution optical absolute encoder
- Brakes in all axes
- Internal cable routing
- Tool I/O connection: AWG#32, DI x 2, DO x 2, AI x 2

S0 is a collaborative robot arm with a foldable design that makes path selection more flexible and increases production efficiency.

cpcStudio - Robot package

Multifunctional control

cpc Robot - User Interface enables direct control of the robot arm's movements. The user can move the end point or the joint freely by tapping. The user can also move the robot arm precisely by specifying the target position of the end point or the joint angle.

Highly User-Friendly Teaching Kit

The user can select different paths and teaching methods, including points (up to 20 points), path recording function (max. 2 minutes by hand guidance), and can select multiple points to execute movement commands in different ways.

cpcRobot architecture

The download area is only available to registered users.
